Below we present our aluminum rolled product range.
You can also benefit from our extensive services such as sawing, longitudinal and cross-sectioning, protective wrapping, re-coiling and surface treatment.
As your partner, we will gladly work with you, offering consulting, storage, and processing of your aluminum products until delivery.
| Standard sheets | |
|---|---|
| EN AW 1050 H14/H24 | Al99,5 F11/G11 |
| EN AW1050 0/H111 | Al99,5 W7 |
| EN AW1050 H18 | Al99,5 F15 |
| EN AW5754 H22 | AlMg3 G22 |
| EN AW5754 h111 | AlMg3 W19 |
| EN AW5005 H14/H24 | AlMg1 F15/G15 NQ |
| Thickness/size | |
|---|---|
| 0,5 - 6,0 mm | 1.000 / 2.000 mm |
| 1.250 / 2.500 mm | |
| 1.500 / 3.000 mm | |
| 1.500 / 4.000 mm | |
| 2.000 / 4.000 mm |
We deliver cuttings and fixed sizes either from the strip or cut with the saw at short notice.
| Sheets - Anodizing quality | |
|---|---|
| EN AW5005 H14 | AlMg1 F15/G15 AQ |
| EN AW 5005 H14 decorative anodizing quality 55HX® with or without protection or laserfoil | |
|---|---|
| Thickness | 1,0 - 3,0 mm |
| Size | 1.000 / 2.000 mm |
| 1.250 / 2.500 mm | |
| 1.500 / 3.000 mm | |
| 1.500 / 4.000 mm |
| EN AW 5005 H14 decorative anodizing quality J57S with one-sided protection foil | |
|---|---|
| Thickness | 2,0 - 4,0 |
| Size | 1.000 / 2.000 mm |
| 1.250 / 2.500 mm | |
| 1.500 / 3.000 mm | |
| 2.000 / 4.000 mm |
| EN AW 5005 H14 Strip anodized E6/EV1 10 or 15 my with one-sided protection foil | |
|---|---|
| Thickness | 1,5 - 3,0 mm |
| Size | 1.000 / 2.000 mm |
| 1.250 / 2.500 mm | |
| 1.500 / 3.000 mm | |
| 2.000 / 4.000 mm |
| Coil-coating color sheets | |
|---|---|
| EN AW 3003 H44 colour sheets | one-sided polyester coated (approx.25my) inc. protection foil Colours: RAL 7016, 9010, 9016, 9006, 9007 |
| Size | 2,0x1500x3000 mm |
| 1,5x1500x3000 mm |
| Mirawall colour sheets | |
|---|---|
| EN AW 3105 H44 colour sheets | one-sided strip powder coated (appox 60my) inc. protection foil Colours: RAL 7016, 9016, 9006, 9007 |
| Size | 2,0x1500x4000 mm |
Processing
Both the coil coating and the Mirawall color sheets can be bent up to 180 degrees with T1 without cracks
Applications
Facade coverings for new and old buildings in Individual and industrial building, advertising signs, industrial housing
| Floorsheets | |
|---|---|
| 2-bar pattern | EN AW5754 H114 (AlMg3W20) |
| 5-bar pattern | bendable |
| Top-Grip Tread height 0,5 or 1,5mm mill finish or pickled | |
| Thickness | 2,0 - 8,0 mm |
| Size | 1.000 / 2.000 mm |
| 1.250 / 2.500 mm | |
| 1.500 / 3.000 mm | |
| 2.000 / 4.000 mm |
We are also happy to offer treadplates in sizes and dimensions not listed on request.
| Rings | |
|---|---|
| Lage coils | Inside diameter: 508 mm Weight: 1 - 2 tons Axis: eye to sky or eye to wall |
| Small coils | Inside diameter: 300 mm |
| after coiling | Weight: 100-200 kg Axis: eye to sky |
| Strips | |
|---|---|
| EN AW1050 H14/H24 | Al99,5 F11/G11 |
| EN AW5049 H22 | AlMg2Mn0,8 G22 |
| EN AW5754 H22 | AlMg3 G22 |
| EN AW5005 H14/H24 | AlMg1 F15/G15 |
We are also pleased to offer other alloys and tempers as well as split strips in widths of 25 to 1500mm in all common alloys.
